LinuCエヴァンジェリストの鯨井貴博@opensourcetechです。

前回記事で作成したKVM環境上のVMにkubeadmでkubernetesクラスターを構築してみます。
今回構築する構成ですが、以下になります。

画像1


なお、kubernetes公式の構築ドキュメントは、以下です。
https://kubernetes.io/ja/docs/setup/production-environment/tools/kubeadm/install-kubeadm/


ここからはクラスターに参加する全ノードで実施します。

始める前に

まず、インストール開始前の確認です。
swapが有効になっていたので、無効化します。
※起動時の読込(/etc/fstab)も忘れないように。

kubeuser@kubemaster1:~$ swapon -s
Filename                                Type            Size    Used    Priority
/swap.img                               file            2097148 524     -2
kubeuser@kubemaster1:~$ sudo swapoff -a
kubeuser@kubemaster1:~$ swapon -s
kubeuser@kubemaster1:~$ sudo vi /etc/fstab
kubeuser@kubemaster1:~$ cat /etc/fstab
# /etc/fstab: static file system information.
#
# Use 'blkid' to print the universally unique identifier for a
# device; this may be used with UUID= as a more robust way to name devices
# that works even if disks are added and removed. See fstab(5).
#
# <file system> <mount point>   <type>  <options>       <dump>  <pass>
# / was on /dev/ubuntu-vg/ubuntu-lv during curtin installation
/dev/disk/by-id/dm-uuid-LVM-P0dKrKHJE2vSGmg4XOnabjUBNgi9Rq9knLPD3QGY4RJYHxFUsYOFRVyxJwUnB92O / ext4 defaults 0 1
# /boot was on /dev/vda2 during curtin installation
/dev/disk/by-uuid/6aa1b86e-f727-4312-8a35-2f7d6a7e5d23 /boot ext4 defaults 0 1
#/swap.img      none    swap    sw      0       0


iptablesがブリッジを通過するトラフィックを処理できるようにする

br_netfilterモジュールのロード。

kubeuser@kubeworker2:~$ lsmod | grep br_netfilter
kubeuser@kubeworker2:~$ sudo modprobe br_netfilter
[sudo] password for kubeuser:
kubeuser@kubeworker2:~$ lsmod | grep br_netfilter
br_netfilter           28672  0
bridge                176128  1 br_netfilter

そして、Linuxノードのiptablesがブリッジを通過するトラフィックを正確に処理するための設定をします。

kubeuser@kubemaster1:~$ sudo vi /etc/sysctl.d/k8s.conf
ubeuser@kubemaster1:~$ cat /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
kubeuser@kubemaster1:~$ sudo sysctl --system
* Applying /etc/sysctl.d/10-console-messages.conf ...
kernel.printk = 4 4 1 7
* Applying /etc/sysctl.d/10-ipv6-privacy.conf ...
net.ipv6.conf.all.use_tempaddr = 2
net.ipv6.conf.default.use_tempaddr = 2
* Applying /etc/sysctl.d/10-kernel-hardening.conf ...
kernel.kptr_restrict = 1
* Applying /etc/sysctl.d/10-link-restrictions.conf ...
fs.protected_hardlinks = 1
fs.protected_symlinks = 1
* Applying /etc/sysctl.d/10-magic-sysrq.conf ...
kernel.sysrq = 176
* Applying /etc/sysctl.d/10-network-security.conf ...
net.ipv4.conf.default.rp_filter = 2
net.ipv4.conf.all.rp_filter = 2
* Applying /etc/sysctl.d/10-ptrace.conf ...
kernel.yama.ptrace_scope = 1
* Applying /etc/sysctl.d/10-zeropage.conf ...
vm.mmap_min_addr = 65536
* Applying /usr/lib/sysctl.d/50-default.conf ...
net.ipv4.conf.default.promote_secondaries = 1
sysctl: setting key "net.ipv4.conf.all.promote_secondaries": Invalid argument
net.ipv4.ping_group_range = 0 2147483647
net.core.default_qdisc = fq_codel
fs.protected_regular = 1
fs.protected_fifos = 1
* Applying /usr/lib/sysctl.d/50-pid-max.conf ...
kernel.pid_max = 4194304
* Applying /etc/sysctl.d/99-sysctl.conf ...
* Applying /etc/sysctl.d/k8s.conf ...
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
* Applying /usr/lib/sysctl.d/protect-links.conf ...
fs.protected_fifos = 1
fs.protected_hardlinks = 1
fs.protected_regular = 2
fs.protected_symlinks = 1
* Applying /etc/sysctl.conf ...


iptablesがnftablesバックエンドを使用しないようにする

nftablesバックエンドは現在のkubeadmパッケージと互換性がないので、iptables-legacyが使用されるように、変更します。

kubeuser@kubemaster1:~$ sudo update-alternatives --set iptables /usr/sbin/iptables-legacy
kubeuser@kubemaster1:~$ sudo update-alternatives --set ip6tables /usr/sbin/ip6tables-legacy
kubeuser@kubemaster1:~$ sudo update-alternatives --set arptables /usr/sbin/arptables-legacy
update-alternatives: using /usr/sbin/arptables-legacy to provide /usr/sbin/arptables (arptables) in manual mode
kubeuser@kubemaster1:~$ sudo update-alternatives --set ebtables /usr/sbin/ebtables-legacy
update-alternatives: using /usr/sbin/ebtables-legacy to provide /usr/sbin/ebtables (ebtables) in manual mode


ランタイムのインストール

Docker・CRI-O・Containerdなどから選択できますが、
今回はDockerを使いました。
参考:https://kubernetes.io/ja/docs/setup/production-environment/container-runtimes/

kubeuser@kubemaster1:~$ sudo apt install docker.io
[sudo] password for kubeuser:
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
 bridge-utils containerd dns-root-data dnsmasq-base libidn11 pigz runc
 ubuntu-fan
Suggested packages:
 ifupdown aufs-tools cgroupfs-mount | cgroup-lite debootstrap docker-doc
 rinse zfs-fuse | zfsutils
The following NEW packages will be installed:
 bridge-utils containerd dns-root-data dnsmasq-base docker.io libidn11 pigz
 runc ubuntu-fan
0 upgraded, 9 newly installed, 0 to remove and 44 not upgraded.
Need to get 74.5 MB of archives.
After this operation, 361 MB of additional disk space will be used.
Do you want to continue? [Y/n] y
Get:1 http://jp.archive.ubuntu.com/ubuntu focal/universe amd64 pigz amd64 2.4-1 [57.4 kB]
Get:2 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 bridge-utils amd64 1.6-2ubuntu1 [30.5 kB]
Get:3 http://jp.archive.ubuntu.com/ubuntu focal-updates/main amd64 runc amd64 1.0.1-0ubuntu2~20.04.1 [4155 kB]
Get:4 http://jp.archive.ubuntu.com/ubuntu focal-updates/main amd64 containerd amd64 1.5.5-0ubuntu3~20.04.1 [33.0 MB]
Get:5 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 dns-root-data all 2019052802 [5300 B]
Get:6 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 libidn11 amd64 1.33-2.2ubuntu2 [46.2 kB]
Get:7 http://jp.archive.ubuntu.com/ubuntu focal-updates/main amd64 dnsmasq-base amd64 2.80-1.1ubuntu1.4 [315 kB]
Get:8 http://jp.archive.ubuntu.com/ubuntu focal-updates/universe amd64 docker.io amd64 20.10.7-0ubuntu5~20.04.2 [36.9 MB]
Get:9 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 ubuntu-fan all 0.12.13 [34.5 kB]
Fetched 74.5 MB in 32s (2336 kB/s)
Preconfiguring packages ...
Selecting previously unselected package pigz.
(Reading database ... 107919 files and directories currently installed.)
Preparing to unpack .../0-pigz_2.4-1_amd64.deb ...
Unpacking pigz (2.4-1) ...
Selecting previously unselected package bridge-utils.
Preparing to unpack .../1-bridge-utils_1.6-2ubuntu1_amd64.deb ...
Unpacking bridge-utils (1.6-2ubuntu1) ...
Selecting previously unselected package runc.
Preparing to unpack .../2-runc_1.0.1-0ubuntu2~20.04.1_amd64.deb ...
Unpacking runc (1.0.1-0ubuntu2~20.04.1) ...
Selecting previously unselected package containerd.
Preparing to unpack .../3-containerd_1.5.5-0ubuntu3~20.04.1_amd64.deb ...
Unpacking containerd (1.5.5-0ubuntu3~20.04.1) ...
Selecting previously unselected package dns-root-data.
Preparing to unpack .../4-dns-root-data_2019052802_all.deb ...
Unpacking dns-root-data (2019052802) ...
Selecting previously unselected package libidn11:amd64.
Preparing to unpack .../5-libidn11_1.33-2.2ubuntu2_amd64.deb ...
Unpacking libidn11:amd64 (1.33-2.2ubuntu2) ...
Selecting previously unselected package dnsmasq-base.
Preparing to unpack .../6-dnsmasq-base_2.80-1.1ubuntu1.4_amd64.deb ...
Unpacking dnsmasq-base (2.80-1.1ubuntu1.4) ...
Selecting previously unselected package docker.io.
Preparing to unpack .../7-docker.io_20.10.7-0ubuntu5~20.04.2_amd64.deb ...
Unpacking docker.io (20.10.7-0ubuntu5~20.04.2) ...
Selecting previously unselected package ubuntu-fan.
Preparing to unpack .../8-ubuntu-fan_0.12.13_all.deb ...
Unpacking ubuntu-fan (0.12.13) ...
Setting up runc (1.0.1-0ubuntu2~20.04.1) ...
Setting up dns-root-data (2019052802) ...
Setting up libidn11:amd64 (1.33-2.2ubuntu2) ...
Setting up bridge-utils (1.6-2ubuntu1) ...
Setting up pigz (2.4-1) ...
Setting up containerd (1.5.5-0ubuntu3~20.04.1) ...
Created symlink /etc/systemd/system/multi-user.target.wants/containerd.service  → /lib/systemd/system/containerd.service.
Setting up docker.io (20.10.7-0ubuntu5~20.04.2) ...
Adding group `docker' (GID 117) ...
Done.
Created symlink /etc/systemd/system/multi-user.target.wants/docker.service → /lib/systemd/system/docker.service.
Created symlink /etc/systemd/system/sockets.target.wants/docker.socket → /lib/systemd/system/docker.socket.
Setting up dnsmasq-base (2.80-1.1ubuntu1.4) ...
Setting up ubuntu-fan (0.12.13) ...
Created symlink /etc/systemd/system/multi-user.target.wants/ubuntu-fan.service  → /lib/systemd/system/ubuntu-fan.service.
Processing triggers for systemd (245.4-4ubuntu3.11) ...
Processing triggers for man-db (2.9.1-1) ...
Processing triggers for dbus (1.12.16-2ubuntu2.1) ...
Processing triggers for libc-bin (2.31-0ubuntu9.2) ...


kubeadm、kubelet、kubectlのインストール

apt-transport-httpsとcurlのインストール。
これからの作業用に必要なものです。

kubeuser@kubemaster1:~$ sudo apt update && sudo apt install apt-transport-https curl
Hit:1 http://jp.archive.ubuntu.com/ubuntu focal InRelease
Get:2 http://jp.archive.ubuntu.com/ubuntu focal-updates InRelease [114 kB]
Get:3 http://jp.archive.ubuntu.com/ubuntu focal-backports InRelease [108 kB]
Get:4 http://jp.archive.ubuntu.com/ubuntu focal-security InRelease [114 kB]
Fetched 336 kB in 3s (114 kB/s)
Reading package lists... Done
Building dependency tree
Reading state information... Done
44 packages can be upgraded. Run 'apt list --upgradable' to see them.
Reading package lists... Done
Building dependency tree
Reading state information... Done
curl is already the newest version (7.68.0-1ubuntu2.7).
curl set to manually installed.
The following NEW packages will be installed:
 apt-transport-https
0 upgraded, 1 newly installed, 0 to remove and 44 not upgraded.
Need to get 4680 B of archives.
After this operation, 162 kB of additional disk space will be used.
Do you want to continue? [Y/n] y
Get:1 http://jp.archive.ubuntu.com/ubuntu focal-updates/universe amd64 apt-transport-https all 2.0.6 [4680 B]
Fetched 4680 B in 0s (61.2 kB/s)
Selecting previously unselected package apt-transport-https.
(Reading database ... 108273 files and directories currently installed.)
Preparing to unpack .../apt-transport-https_2.0.6_all.deb ...
Unpacking apt-transport-https (2.0.6) ...
Setting up apt-transport-https (2.0.6) ...

kubernetes用のAPTレポジトリ追加して、レポジトリキャッシュの更新をします。

kubeuser@kubemaster1:~$ sudo vi /etc/apt/sources.list.d/kubernetes.list
kubeuser@kubemaster1:~$ cat /etc/apt/sources.list.d/kubernetes.list
deb http://apt.kubernetes.io/ kubernetes-xenial main
kubeuser@kubemaster1:~$ sudo curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
OK
kubeuser@kubemaster1:~$ sudo apt update
Hit:1 http://jp.archive.ubuntu.com/ubuntu focal InRelease
Get:2 http://jp.archive.ubuntu.com/ubuntu focal-updates InRelease [114 kB]
Get:3 http://jp.archive.ubuntu.com/ubuntu focal-backports InRelease [108 kB]
Get:5 http://jp.archive.ubuntu.com/ubuntu focal-security InRelease [114 kB]
Get:4 https://packages.cloud.google.com/apt kubernetes-xenial InRelease [9383 B]
Get:6 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 Packages [51.6 kB]
Fetched 388 kB in 4s (91.4 kB/s)
Reading package lists... Done
Building dependency tree
Reading state information... Done
44 packages can be upgraded. Run 'apt list --upgradable' to see them.

kubeadm・kubelet・kubectlをインストールします。

kubeuser@kubemaster1:~$ sudo apt install kubeadm=1.18.0-00 kubelet=1.18.0-00 kubectl=1.18.0-00
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following additional packages will be installed:
 conntrack cri-tools kubernetes-cni socat
Suggested packages:
 nftables
The following NEW packages will be installed:
 conntrack cri-tools kubeadm kubectl kubelet kubernetes-cni socat
0 upgraded, 7 newly installed, 0 to remove and 44 not upgraded.
Need to get 72.9 MB of archives.
After this operation, 301 MB of additional disk space will be used.
Do you want to continue? [Y/n] y
Get:1 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 conntrack amd64 1:1.4.5-2 [30.3 kB]
Get:2 http://jp.archive.ubuntu.com/ubuntu focal/main amd64 socat amd64 1.7.3.3-2 [323 kB]
Get:3 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 cri-tools amd64 1.19.0-00 [11.2 MB]
Get:4 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 kubernetes-cni amd64 0.8.7-00 [25.0 MB]
Get:5 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 kubelet amd64 1.18.0-00 [19.4 MB]
Get:6 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 kubectl amd64 1.18.0-00 [8822 kB]
Get:7 https://packages.cloud.google.com/apt kubernetes-xenial/main amd64 kubeadm amd64 1.18.0-00 [8163 kB]
Fetched 72.9 MB in 13s (5579 kB/s)
Selecting previously unselected package conntrack.
(Reading database ... 108277 files and directories currently installed.)
Preparing to unpack .../0-conntrack_1%3a1.4.5-2_amd64.deb ...
Unpacking conntrack (1:1.4.5-2) ...
Selecting previously unselected package cri-tools.
Preparing to unpack .../1-cri-tools_1.19.0-00_amd64.deb ...
Unpacking cri-tools (1.19.0-00) ...
Selecting previously unselected package kubernetes-cni.
Preparing to unpack .../2-kubernetes-cni_0.8.7-00_amd64.deb ...
Unpacking kubernetes-cni (0.8.7-00) ...
Selecting previously unselected package socat.
Preparing to unpack .../3-socat_1.7.3.3-2_amd64.deb ...
Unpacking socat (1.7.3.3-2) ...
Selecting previously unselected package kubelet.
Preparing to unpack .../4-kubelet_1.18.0-00_amd64.deb ...
Unpacking kubelet (1.18.0-00) ...
Selecting previously unselected package kubectl.
Preparing to unpack .../5-kubectl_1.18.0-00_amd64.deb ...
Unpacking kubectl (1.18.0-00) ...
Selecting previously unselected package kubeadm.
Preparing
kubeuser@kubemaster1:~$ sudo apt-mark hold kubelet kubeadm kubectl
kubelet set on hold.
kubeadm set on hold.
kubectl set on hold.


ここからは1台目のmasterノードのみで実施します。

CNI(Container Networking Interface)の設定

コンテナが稼働するPodネットワークに関する設定。
今回は、Calicoを使いました。
参考:https://kubernetes.io/ja/docs/concepts/cluster-administration/networking/

以下にあるcalico.yamlを編集して使用します。
https://docs.projectcalico.org/manifests/calico.yaml

kubeuser@kubemaster1:~$ wget https://docs.projectcalico.org/manifests/calico.yaml
--2021-12-01 11:03:11--  https://docs.projectcalico.org/manifests/calico.yaml
Resolving docs.projectcalico.org (docs.projectcalico.org)... 2406:da18:880:3800:1655:e904:cce5:66a5, 2400:6180:0:d1::5be:9001, 178.128.124.245, ...
Connecting to docs.projectcalico.org (docs.projectcalico.org)|2406:da18:880:3800:1655:e904:cce5:66a5|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 217525 (212K) [text/yaml]
Saving to: ‘calico.yaml’
calico.yaml         100%[===================>] 212.43K   518KB/s    in 0.4s
2021-12-01 11:03:12 (518 KB/s) - ‘calico.yaml’ saved [217525/217525]
kubeuser@kubemaster1:~$ ls
kubeuser@kubemaster1:~$ cat -n calico.yaml
    1  ---
    2  # Source: calico/templates/calico-config.yaml
    3  # This ConfigMap is used to configure a self-hosted Calico installation.
    4  kind: ConfigMap
    5  apiVersion: v1
    6  metadata:
    7    name: calico-config
.
.
.
 4221              # no effect. This should fall within `--cluster-cidr`.
 4222              # - name: CALICO_IPV4POOL_CIDR
 4223              #   value: "192.168.0.0/16"
 4224              # Disable file logging so `kubectl logs` works.
.
.
.


4222行目、及び4223行目を編集します。
※どのサブネットを使うかは、それぞれの環境に合わせてください。

 4221              # no effect. This should fall within `--cluster-cidr`.
 4222              - name: CALICO_IPV4POOL_CIDR
 4223                value: "10.0.0.0/16"
 4224              # Disable file logging so `kubectl logs` works.

/etc/hostsを編集します。
※クラスターを組む、masterノード3台・workerノード2台分を追記しています。

kubeuser@kubemaster1:~$ sudo vi /etc/hosts
kubeuser@kubemaster1:~$ cat /etc/hosts
127.0.0.1 localhost
127.0.1.1 kube_master1
192.168.1.251 k8smaster1
192.168.1.252 k8smaster2
192.168.1.249 k8smaster3
192.168.1.253 k8sworker
192.168.1.254 k8sworker2
# The following lines are desirable for IPv6 capable hosts
::1     ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters


kubeadm-config.yamlの編集

kubeuser@kubemaster1:~$ sudo vi kubeadm-config.yaml
kubeuser@kubemaster1:~$ cat kubeadm-config.yaml
apiVersion: kubeadm.k8s.io/v1beta2
kind: ClusterConfiguration
kubernetesVersion: 1.18.0
controlPlaneEndpoint: "k8smaster1:6443"
networking:
 podSubnet: 10.0.0.0/16 ・・・ここを編集(calico.yamlのCALICO_IPV4POOL_CIDRと一致させる)


kubeadm initを実行して、クラスター1台目のmasterノードを組み込みます。
出力の最後に、masterノード・workerノードを追加するためのコマンドが出力されます。

kubeuser@kubemaster1:~$ sudo kubeadm init --config=kubeadm-config.yaml --upload-certs | tee kubeadm-init.out
W1201 11:21:16.673692   49217 configset.go:202] WARNING: kubeadm cannot validate component configs for API groups [kubelet.config.k8s.io kubeproxy.config.k8s.io]
[init] Using Kubernetes version: v1.18.0
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
       [WARNING SystemVerification]: this Docker version is not on the list of validated versions: 20.10.7. Latest validated version: 19.03
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubemaster1 kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local k8smaster1] and IPs [10.96.0.1 192.168.1.251]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [kubemaster1 localhost] and IPs [192.168.1.251 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [kubemaster1 localhost] and IPs [192.168.1.251 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
W1201 11:22:21.499446   49217 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[control-plane] Creating static Pod manifest for "kube-scheduler"
W1201 11:22:21.500873   49217 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 32.507684 seconds
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[kubelet] Creating a ConfigMap "kubelet-config-1.18" in namespace kube-system with the configuration for the kubelets in the cluster
[upload-certs] Storing the certificates in Secret "kubeadm-certs" in the "kube-system" Namespace
[upload-certs] Using certificate key:
3017c568250f52e8e22d2b3a5b8838f071016c0fe5e740c38652f85ffa99198a
[mark-control-plane] Marking the node kubemaster1 as control-plane by adding the label "node-role.kubernetes.io/master=''"
[mark-control-plane] Marking the node kubemaster1 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
[bootstrap-token] Using token: cde4rl.f5gk2l5tt0k45nkh
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[addons] Applied essential addon: kube-proxy
Your Kubernetes control-plane has initialized successfully!
To start using your cluster, you need to run the following as a regular user:
 mkdir -p $HOME/.kube
 sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
 sudo chown $(id -u):$(id -g) $HOME/.kube/config
You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
 https://kubernetes.io/docs/concepts/cluster-administration/addons/
You can now join any number of the control-plane node running the following command on each as root:
 kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh \
   --disco
kubeuser@kubemaster1:~$ ls
calico.yaml  kubeadm-config.yaml  kubeadm-init.out

kubectlコマンドを現在のユーザーで実行できるようにします。
※このコマンドも、kubeadm initの出力に含まれています。

kubeuser@kubemaster1:~$ mkdir -p $HOME/.kube
kubeuser@kubemaster1:~$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
kubeuser@kubemaster1:~$ ls -la $HOME/.kube/config
-rw------- 1 root root 5450 Dec  1 11:28 /home/kubeuser/.kube/config
kubeuser@kubemaster1:~$ sudo chown $(id -u):$(id -g) $HOME/.kube/config
kubeuser@kubemaster1:~$ ls -la $HOME/.kube/config
-rw------- 1 kubeuser kubeuser 5450 Dec  1 11:28 /home/kubeuser/.kube/config
kubeuser@kubemaster1:~$ cat ~/.kube/config
apiVersion: v1
clusters:
- cluster:
   certificate-authority-data: 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
   server: https://k8smaster1:6443
 name: kubernetes
contexts:
- context:
   cluster: kubernetes
   user: kubernetes-admin
 name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
 user:
   client-certificate-data: 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
   client-key-data: LS0tLS1CRUdJTiBSU0EgUFJJVkFURSBLRVktLS0tLQpNSUlFcFFJQkFBS0NBUUVBdG5HcHI5WDFNS0xtWGFzTlB0SzhVMmU3UzRRam9leVF3UEk3U0o1b0JLRUhqUmQxCmQ1QVFFcVRqNGlsWWk4NXJ2ckNHNldULzhFbTR4VDF2SGJNRG1nQzFzcVVlSDYxdEx6UDhJZDhLSVIyckRmRUIKT1MvdThGeVV5SlBnK3lUQ05pUldZNnlTbWwvY1pVUU1TbWw3V1QyT1ZrTXc5Qmt2RHEzY0YzMURXVlZER0tJdAp0Q3FwRnd3UHVYcTY3TGg2eEcvOWkrTlRhU3RhWU9xT2NsTkVzcUNTaDFXVVJDYmVrZmtJNDhUZExnWXdHSS95ClVXbGlsYTJHNTM5VFJWQS9zaklUelJsdWxldUljbWFxb1hiYk04Sk0xdFJhdjJCV0U2Rm1WNDZxRXYybzFQVi8KWTNkUXdnTnhXQklxZnk2dXNnZmh6NW5qR3YrcFhSVmpaR2h6c3dJREFRQUJBb0lCQUFNdDI5MGFoMWsvblhBSQphUVN0TzJiZ3FkelpBcDN4dDF3RlhJOFpZNHFoRzdhVHNCSlRTbFJvMXllN3ZMVkM5Wkd2RmNxL1hjNWNHb0lsClhlaFFsRUY4dmEzTlBzY2lpSUtJRDE2dnVrZDFjdU9kVFg0bm5heEdrTGttQ29lVnptU1BJWW8vR1piakVMNGEKLzNQVWZyZkJZTmVUK0Nob3YrOHJqR2hFWUlZUDlMaklIZkJYR3JnWXE4VWZ5bndRakJBTVJvbFd0UjEva1NpSQpSOEdGMVVWOXloVnpPV2oxQ0ltWWdPbkJ2STBsZEMrUHVLaUZqNlF6OGVFU1JWaXhic29xUGhsWkFtbk5wTVliCjkvTk5oZmtPSXRGMGdBMGViQXFvZXRxdkZHYkw0RkFqVU9Hak5pNGpESTFFUmNuRWpSOXRLaEhDeWRDa2RhQjQKcFdyZ1dlRUNnWUVBN1VodXAyQkMyWE1zSVlQL0EyaEE4YWFlRHlWUDJ4TGxJN2Z4bThLR2QyeFFmNUR4QzJjVQowT2JTUmNwMnNqN3IyWXk1d2ZrUWJ1THZlR2RXWWpDS0VlNVo5WEJKTXdTYmVGSXBDY0QwUll2b2YwdG4xR2tLCkRkQU1LcXEweHFlc3NmT1hXRmlWVkg4ekNyQ0xBdXlHTW9TYnFvK1VwYlhVZHNMaFV2QndZSWtDZ1lFQXhOWFgKZEVxMGRwbXpJSGZ2ZWEzdVVQRHBIUjAzNkYvOEYwRVZrNjcrMW1TUDFVTTJuSXk0RFJSRzdhSG0relpqSGtiUQpUNnlWNDV4ckdKV2xmRXd4Y25OY1VaQ1Nhblh6azRzNkIwTFFUeU1lYlQ1MmY3S1dsU0s4eThkUldjN0kzcXJCCkFaM3FpMjBoWlQwV1lyNkUzZXR6ODFnSjBYbElSM2NzQk9jK1Mxc0NnWUVBczMyeUxxeVRoUGdwYnVUeGQvdFoKL1RKRHFFTmFSK2JnTElmTm5UeW1DUnFIUGlnL0hwZ0lXQW56RDlZYXViVDlKZURjOTQxWFQvb2NtZURacUliOQpPcGtwdFk4TjRDamhEa0JnU0wrTVNEdVFVUktTWlV4YnpaME9Sd3hBbVhGbkltbVlsN3pTb1V0aktmZm4vL3M1CmZHZHhkYkVOQ2RrazhmMXpBeEZjZ0xrQ2dZRUFsbkhIZ3JnU3BNK25UTHEreStiM3p0


kubectlコマンドが実行できるようになりました。

kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE    VERSION
kubemaster1   NotReady   master   8m7s   v1.18.0


編集済みのcalico.yamlからcalicoを起動します。
※コンテナとして起動します。

kubeuser@kubemaster1:~$ ls
calico.yaml  kubeadm-config.yaml  kubeadm-init.out
kubeuser@kubemaster1:~$ kubectl apply -f calico.yaml
configmap/calico-config created
customresourcedefinition.apiextensions.k8s.io/bgpconfigurations.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/bgppeers.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/blockaffinities.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/caliconodestatuses.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/clusterinformations.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/felixconfigurations.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/globalnetworkpolicies.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/globalnetworksets.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/hostendpoints.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/ipamblocks.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/ipamconfigs.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/ipamhandles.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/ippools.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/ipreservations.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/kubecontrollersconfigurations.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/networkpolicies.crd.projectcalico.org created
customresourcedefinition.apiextensions.k8s.io/networksets.crd.projectcalico.org created
clusterrole.rbac.authorization.k8s.io/calico-kube-controllers created
clusterrolebinding.rbac.authorization.k8s.io/calico-kube-controllers created
clusterrole.rbac.authorization.k8s.io/calico-node created
clusterrolebinding.rbac.authorization.k8s.io/calico-node created
daemonset.apps/calico-node created
serviceaccount/calico-node created
deployment.apps/calico-kube-controllers created
serviceaccount/calico-kube-controllers created
poddisruptionbudget.policy/calico-kube-controllers created


「-n kube-system」を付けるとcalicoなどのコンテナ(Pod)が確認でき、
数秒毎にkubectl get podsを実行すると、そのステータス変化も確認できます。

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          15s
calico-node-7t474                          0/1     Init:0/3   0          15s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          10m
kube-apiserver-kubemaster1                 1/1     Running    0          10m
kube-controller-manager-kubemaster1        1/1     Running    0          10m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          10m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          33s
calico-node-7t474                          0/1     Init:1/3   0          33s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          10m
kube-apiserver-kubemaster1                 1/1     Running    0          10m
kube-controller-manager-kubemaster1        1/1     Running    0          10m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          10m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          37s
calico-node-7t474                          0/1     Init:2/3   0          37s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          10m
kube-apiserver-kubemaster1                 1/1     Running    0          10m
kube-controller-manager-kubemaster1        1/1     Running    0          10m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          10m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          38s
calico-node-7t474                          0/1     Init:2/3   0          38s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          10m
kube-apiserver-kubemaster1                 1/1     Running    0          10m
kube-controller-manager-kubemaster1        1/1     Running    0          10m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          10m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          42s
calico-node-7t474                          0/1     Init:2/3   0          42s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          11m
kube-apiserver-kubemaster1                 1/1     Running    0          11m
kube-controller-manager-kubemaster1        1/1     Running    0          11m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          44s
calico-node-7t474                          0/1     Init:2/3   0          44s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          11m
kube-apiserver-kubemaster1                 1/1     Running    0          11m
kube-controller-manager-kubemaster1        1/1     Running    0          11m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS     RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending    0          45s
calico-node-7t474                          0/1     Init:2/3   0          45s
coredns-66bff467f8-cpd25                   0/1     Pending    0          10m
coredns-66bff467f8-wtww9                   0/1     Pending    0          10m
etcd-kubemaster1                           1/1     Running    0          11m
kube-apiserver-kubemaster1                 1/1     Running    0          11m
kube-controller-manager-kubemaster1        1/1     Running    0          11m
kube-proxy-6gq55                           1/1     Running    0          10m
kube-scheduler-kubemaster1                 1/1     Running    0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Pending             0          47s
calico-node-7t474                          0/1     Init:2/3            0          47s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          10m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          10m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          10m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          51s
calico-node-7t474                          0/1     Init:2/3            0          51s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          53s
calico-node-7t474                          0/1     PodInitializing     0          53s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          55s
calico-node-7t474                          0/1     PodInitializing     0          55s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          58s
calico-node-7t474                          0/1     PodInitializing     0          58s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          60s
calico-node-7t474                          0/1     PodInitializing     0          60s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          62s
calico-node-7t474                          0/1     PodInitializing     0          62s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          65s
calico-node-7t474                          0/1     PodInitializing     0          65s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          68s
calico-node-7t474                          0/1     PodInitializing     0          68s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          71s
calico-node-7t474                          0/1     PodInitializing     0          71s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          76s
calico-node-7t474                          0/1     PodInitializing     0          76s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          80s
calico-node-7t474                          0/1     PodInitializing     0          80s
coredns-66bff467f8-cpd25                   0/1     ContainerCreating   0          11m
coredns-66bff467f8-wtww9                   0/1     ContainerCreating   0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS              RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     ContainerCreating   0          99s
calico-node-7t474                          1/1     Running             0          99s
coredns-66bff467f8-cpd25                   1/1     Running             0          11m
coredns-66bff467f8-wtww9                   1/1     Running             0          11m
etcd-kubemaster1                           1/1     Running             0          11m
kube-apiserver-kubemaster1                 1/1     Running             0          11m
kube-controller-manager-kubemaster1        1/1     Running             0          11m
kube-proxy-6gq55                           1/1     Running             0          11m
kube-scheduler-kubemaster1                 1/1     Running             0          11m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS    RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   0/1     Running   0          102s
calico-node-7t474                          1/1     Running   0          102s
coredns-66bff467f8-cpd25                   1/1     Running   0          11m
coredns-66bff467f8-wtww9                   1/1     Running   0          11m
etcd-kubemaster1                           1/1     Running   0          12m
kube-apiserver-kubemaster1                 1/1     Running   0          12m
kube-controller-manager-kubemaster1        1/1     Running   0          12m
kube-proxy-6gq55                           1/1     Running   0          11m
kube-scheduler-kubemaster1                 1/1     Running   0          12m

kubeuser@kubemaster1:~$ kubectl get pods -n kube-system
NAME                                       READY   STATUS    RESTARTS   AGE
calico-kube-controllers-77ff9c69dd-m5jbz   1/1     Running   0          106s
calico-node-7t474                          1/1     Running   0          106s
coredns-66bff467f8-cpd25                   1/1     Running   0          11m
coredns-66bff467f8-wtww9                   1/1     Running   0          11m
etcd-kubemaster1                           1/1     Running   0          12m
kube-apiserver-kubemaster1                 1/1     Running   0          12m
kube-controller-manager-kubemaster1        1/1     Running   0          12m
kube-proxy-6gq55                           1/1     Running   0          11m
kube-scheduler-kubemaster1                 1/1     Running   0          12m

kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE   VERSION
kubemaster1   Ready    master   12m   v1.18.0


kubeadm-config.yamlに関する内容もコマンドで確認ができます。

kubeuser@kubemaster1:~$ sudo kubeadm config print init-defaults
W1201 11:39:51.998223   62685 configset.go:202] WARNING: kubeadm cannot validate component configs for API groups [kubelet.config.k8s.io kubeproxy.config.k8s.io]
apiVersion: kubeadm.k8s.io/v1beta2
bootstrapTokens:
- groups:
 - system:bootstrappers:kubeadm:default-node-token
 token: abcdef.0123456789abcdef
 ttl: 24h0m0s
 usages:
 - signing
 - authentication
kind: InitConfiguration
localAPIEndpoint:
 advertiseAddress: 1.2.3.4
 bindPort: 6443
nodeRegistration:
 criSocket: /var/run/dockershim.sock
 name: kubemaster1
 taints:
 - effect: NoSchedule
   key: node-role.kubernetes.io/master
---
apiServer:
 timeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta2
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controllerManager: {}
dns:
 type: CoreDNS
etcd:
 local:
   dataDir: /var/lib/etcd
imageReposit


ここからは1台目のworkerノードで操作をします。

Workerノードの追加

/etc/hostsの編集。

kubeuser@kubeworker:~$ cat /etc/hosts
127.0.0.1 localhost
127.0.1.1 kube_worker
192.168.1.251 k8smaster1
192.168.1.252 k8smaster2
192.168.1.249 k8smaster3
192.168.1.253 k8sworker
192.168.1.254 k8sworker
# The following lines are desirable for IPv6 capable hosts
::1     ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters


masterで出力された"kubeadm join"を確認します。

kubeuser@kubemaster1:~$ ls
calico.yaml  kubeadm-config.yaml  kubeadm-init.out
kubeuser@kubemaster1:~$ cat kubeadm-init.out
.
.
.
kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh \
   --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae


kubeadm joinの実行。

kubeuser@kubeworker:~$ sudo kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh     --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae
W1201 11:53:27.578257   19408 join.go:346] [preflight] WARNING: JoinControlPane.controlPlane settings will be ignored when control-plane flag is not set.
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
       [WARNING SystemVerification]: this Docker version is not on the list of validated versions: 20.10.7. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml'
[kubelet-start] Downloading configuration for the kubelet from the "kubelet-config-1.18" ConfigMap in the kube-system namespace
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.
Run 'kubectl get nodes' on the control-plane to see this node join the cluster.


masterノードで"kubectl get nodes"を実行すると、1分過ぎたあたりで"Ready"となることが確認できます。

kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE   VERSION
kubemaster1   Ready    master   30m   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE   VERSION
kubemaster1   Ready      master   30m   v1.18.0
kubeworker    NotReady   <none>   1s    v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE   VERSION
kubemaster1   Ready      master   31m   v1.18.0
kubeworker    NotReady   <none>   27s   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE   VERSION
kubemaster1   Ready      master   31m   v1.18.0
kubeworker    NotReady   <none>   43s   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE   VERSION
kubemaster1   Ready      master   31m   v1.18.0
kubeworker    NotReady   <none>   68s   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE   VERSION
kubemaster1   Ready    master   32m   v1.18.0
kubeworker    Ready    <none>   73s   v1.18.0

続いて、2台目のmasterノードで操作します。

Masterノードの追加

/etc/hostsの編集。

kubeuser@kubemaster2:~$ cat /etc/hosts
127.0.0.1 localhost
127.0.1.1 kube_master2
192.168.1.251 k8smaster1
192.168.1.252 k8smaster2
192.168.1.249 k8smaster3
192.168.1.253 k8sworker
192.168.1.254 k8sworker2
# The following lines are desirable for IPv6 capable hosts
::1     ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters


masterノードの"kubeadm join"を確認します。

kubeuser@kubemaster1:~$ ls
calico.yaml  kubeadm-config.yaml  kubeadm-init.out
kubeuser@kubemaster1:~$ cat kubeadm-init.out
.
.
.
You can now join any number of the control-plane node running the following command on each as root:
 kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh \
   --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae \
   --control-plane --certificate-key 3017c568250f52e8e22d2b3a5b8838f071016c0fe5e740c38652f85ffa99198a
.
.
.


kubeadm joinを実行します。

kubeuser@kubemaster2:~$ sudo kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh \
>     --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae \
>     --control-plane --certificate-key 3017c568250f52e8e22d2b3a5b8838f071016c0fe5e740c38652f85ffa99198a
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
       [WARNING SystemVerification]: this Docker version is not on the list of validated versions: 20.10.7. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml'
[preflight] Running pre-flight checks before initializing the new control plane instance
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[download-certs] Downloading the certificates in Secret "kubeadm-certs" in the "kube-system" Namespace
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubemaster2 kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local k8smaster1] and IPs [10.96.0.1 192.168.1.252]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [kubemaster2 localhost] and IPs [192.168.1.252 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [kubemaster2 localhost] and IPs [192.168.1.252 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Valid certificates and keys now exist in "/etc/kubernetes/pki"
[certs] Using the existing "sa" key
[kubeconfig] Generating kubeconfig files
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
W1201 12:00:06.325890   20690 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
W1201 12:00:06.337079   20690 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[control-plane] Creating static Pod manifest for "kube-scheduler"
W1201 12:00:06.338505   20690 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[check-etcd] Checking that the etcd cluster is healthy
[kubelet-start] Downloading configuration for the kubelet from the "kubelet-config-1.18" ConfigMap in the kube-system namespace
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
[etcd] Announced new etcd member joining to the existing etcd cluster
[etcd] Creating static Pod manifest for "etcd"
[etcd] Waiting for the new etcd member to join the cluster. This can take up to 40s
[kubelet-check] Initial timeout of 40s passed.
{"level":"warn","ts":"2021-12-01T12:01:02.843Z","caller":"clientv3/retry_interceptor.go:61","msg":"retrying of unary invoker failed","target":"passthrough:///https://192.168.1.252:2379","attempt":0,"error":"rpc error: code = DeadlineExceeded desc = context deadline exceeded"}
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[mark-control-plane] Marking the node kubemaster2 as control-plane by adding the label "node-role.kubernetes.io/master=''"
[mark-control-plane] Marking the node kubemaster2 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
This node has joined the cluster and a new control plane instance was created:
* Certificate signing request was sent to apiserver and approval was received.
* The Kubelet was informed of the new secure connection details.
* Control plane (master) label and taint were applied to the new node.
* The Kubernetes control plane instances scaled up.
* A new etcd member was added to the local/stacked etcd cluster.
To start administering your cluster from this node, you need to run the following as a regular user:
       mkdir -p $HOME/.kube
       sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
       sudo chown $(id -u):$(id -g) $HOME/.kube/config
Run 'kubectl get nodes' to see this node join the cluster.


ノードの追加されていく過程。

kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE     VERSION
kubemaster1   Ready    master   37m     v1.18.0
kubeworker    Ready    <none>   6m35s   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
Error from server: etcdserver: request timed out
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS     ROLES    AGE     VERSION
kubemaster1   Ready      master   38m     v1.18.0
kubemaster2   NotReady   <none>   60s     v1.18.0
kubeworker    Ready      <none>   7m36s   v1.18.0
kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE    VERSION
kubemaster1   Ready    master   38m    v1.18.0
kubemaster2   Ready    master   85s    v1.18.0
kubeworker    Ready    <none>   8m1s   v1.18.0


ユーザによるkubectlの実行環境の設定。

kubeuser@kubemaster2:~$ mkdir -p $HOME/.kube
kubeuser@kubemaster2:~$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
kubeuser@kubemaster2:~$ sudo chown $(id -u):$(id -g) $HOME/.kube/config
kubeuser@kubemaster2:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE     VERSION
kubemaster1   Ready    master   40m     v1.18.0
kubemaster2   Ready    master   3m15s   v1.18.0
kubeworker    Ready    <none>   9m51s   v1.18.0

ノード追加時のトークンの確認。

kubeuser@kubemaster1:~$ sudo kubeadm token list
[sudo] password for kubeuser:
TOKEN                     TTL         EXPIRES                USAGES                   DESCRIPTION                                                EXTRA GROUPS
cde4rl.f5gk2l5tt0k45nkh   23h         2021-12-02T11:22:55Z   authentication,signing   <none>                                                     system:bootstrappers:kubeadm:default-node-token
qy7yo2.tfic23hneed7cpuu   1h          2021-12-01T13:22:54Z   <none>                   Proxy for managing TTL for the kubeadm-certs secret        <none>

Token期限切れ時の対応

ノード(master/worker)追加時に発行されたトークンの期限(24時間)を過ぎた場合、
以下のようにエラーとなります。

kubeuser@kubeworker2:~$ kubeadm join k8smaster1:6443 --token cde4rl.f5gk2l5tt0k45nkh \
   --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae
W1201 12:47:00.138352   18523 join.go:346] [preflight] WARNING: JoinControlPane.controlPlane settings will be ignored when control-plane flag is not set.
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
error execution phase preflight: couldn't validate the identity of the API Server: could not find a JWS signature in the cluster-info ConfigMap for token ID "cde4rl"
To see the stack trace of this error execute with --v=5 or higher


どのようにするかというと、トークンの作成でOKです。
あたらに作成されたトークンに"kubeamd join"のオプションを変更すれば大丈夫。

kubeuser@kubemaster1:~$ sudo kubeadm token create
W1201 12:20:28.289334  103522 configset.go:202] WARNING: kubeadm cannot validate component configs for API groups [kubelet.config.k8s.io kubeproxy.config.k8s.io]
lfa4k5.6k57rdwzrvo4sar8
kubeuser@kubemaster1:~$ sudo kubeadm token list
TOKEN                     TTL         EXPIRES                USAGES                   DESCRIPTION                                                EXTRA GROUPS
cde4rl.f5gk2l5tt0k45nkh   23h         2021-12-02T11:22:55Z   authentication,signing   <none>                                                     system:bootstrappers:kubeadm:default-node-token
lfa4k5.6k57rdwzrvo4sar8   23h         2021-12-02T12:20:28Z   authentication,signing   <none>                                                     system:bootstrappers:kubeadm:default-node-token
qy7yo2.tfic23hneed7cpuu   1h          2021-12-01T13:22:54Z   <none>                   Proxy for managing TTL for the kubeadm-certs secret        <none>


では確かめてみましょう。
2台目のworkerノートの追加。
/etc/hostsを編集して、kubeadm joinを実行します。

kubeuser@kubeworker2:~$ sudo vi /etc/hosts
[sudo] password for kubeuser:
kubeuser@kubeworker2:~$ cat /etc/hosts
127.0.0.1 localhost
127.0.1.1 kube_worker2
192.168.1.251 k8smaster1
192.168.1.252 k8smaster2
192.168.1.249 k8smaster3
192.168.1.253 k8sworker
192.168.1.254 k8sworker2
# The following lines are desirable for IPv6 capable hosts
::1     ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters
kubeuser@kubeworker2:~$ sudo kubeadm join k8smaster1:6443 --token lfa4k5.6k57rdw
zrvo4sar8     --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4
ce6fe1371238a68833b8293a72580b0a08ae
W1201 12:23:19.569456   23296 join.go:346] [preflight] WARNING: JoinControlPane.controlPlane settings will be ignored when control-plane flag is not set.
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
       [WARNING SystemVerification]: this Docker version is not on the list of validated versions: 20.10.7. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml'
[kubelet-start] Downloading configuration for the kubelet from the "kubelet-config-1.18" ConfigMap in the kube-system namespace
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.
Run 'kubectl get nodes' on the control-plane to see this node join the cluster.


3台目のmasterノードでも同様にできます。

kubeuser@kubemaster3:~$ sudo vi /etc/hosts
[sudo] password for kubeuser:
kubeuser@kubemaster3:~$ cat /etc/hosts
127.0.0.1 localhost
127.0.1.1 kube_master3
192.168.1.251 k8smaster1
192.168.1.252 k8smaster2
192.168.1.249 k8smaster3
192.168.1.253 k8sworker
192.168.1.254 k8sworker2
# The following lines are desirable for IPv6 capable hosts
::1     ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters
kubeuser@kubemaster3:~$ sudo kubeadm join k8smaster1:6443 --token lfa4k5.6k57rdwzrvo4sar8 \
>     --discovery-token-ca-cert-hash sha256:239cf7568930a6eca59742e0d1d4ce6fe1371238a68833b8293a72580b0a08ae \
>     --control-plane --certificate-key 3017c568250f52e8e22d2b3a5b8838f071016c0fe5e740c38652f85ffa99198a
[preflight] Running pre-flight checks
       [WARNING IsDockerSystemdCheck]: detected "cgroupfs" as the Docker cgroup driver. The recommended driver is "systemd". Please follow the guide at https://kubernetes.io/docs/setup/cri/
       [WARNING SystemVerification]: this Docker version is not on the list of validated versions: 20.10.7. Latest validated version: 19.03
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -oyaml'
[preflight] Running pre-flight checks before initializing the new control plane instance
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[download-certs] Downloading the certificates in Secret "kubeadm-certs" in the "kube-system" Namespace
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [kubemaster3 localhost] and IPs [192.168.1.249 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [kubemaster3 localhost] and IPs [192.168.1.249 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubemaster3 kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local k8smaster1] and IPs [10.96.0.1 192.168.1.249]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Valid certificates and keys now exist in "/etc/kubernetes/pki"
[certs] Using the existing "sa" key
[kubeconfig] Generating kubeconfig files
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
W1201 12:27:45.927652   24196 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
W1201 12:27:45.945850   24196 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[control-plane] Creating static Pod manifest for "kube-scheduler"
W1201 12:27:45.947338   24196 manifests.go:225] the default kube-apiserver authorization-mode is "Node,RBAC"; using "Node,RBAC"
[check-etcd] Checking that the etcd cluster is healthy
[kubelet-start] Downloading configuration for the kubelet from the "kubelet-config-1.18" ConfigMap in the kube-system namespace
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
[etcd] Announced new etcd member joining to the existing etcd cluster
[etcd] Creating static Pod manifest for "etcd"
[etcd] Waiting for the new etcd member to join the cluster. This can take up to 40s
{"level":"warn","ts":"2021-12-01T12:28:17.138Z","caller":"clientv3/retry_interceptor.go:61","msg":"retrying of unary invoker failed","target":"passthrough:///https://192.168.1.249:2379","attempt":0,"error":"rpc error: code = DeadlineExceeded desc = context deadline exceeded"}
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[mark-control-plane] Marking the node kubemaster3 as control-plane by adding the label "node-role.kubernetes.io/master=''"
[mark-control-plane] Marking the node kubemaster3 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
This node has joined the cluster and a new control plane instance was created:
* Certificate signing request was sent to apiserver and approval was received.
* The Kubelet was informed of the new secure connection details.
* Control plane (master) label and taint were applied to the new node.
* The Kubernetes control plane instances scaled up.
* A new etcd member was added to the local/stacked etcd cluster.
To start administering your cluster from this node, you need to run the following as a regular user:
       mkdir -p $HOME/.kube
       sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
       sudo chown $(id -u):$(id -g) $HOME/.kube/config
Run 'kubectl get nodes' to see this node join the cluster.
kubeuser@kubemaster3:~$ mkdir -p $HOME/.kube
kubeuser@kubemaster3:~$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
kubeuser@kubemaster3:~$ sudo chown $(id -u):$(id -g) $HOME/.kube/config
kubeuser@kubemaster3:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE     VERSION
kubemaster1   Ready    master   66m     v1.18.0
kubemaster2   Ready    master   29m     v1.18.0
kubemaster3   Ready    master   104s    v1.18.0
kubeworker    Ready    <none>   36m     v1.18.0
kubeworker2   Ready    <none>   5m54s   v1.18.0


kubernetesクラスターの完成

これでkubernetesクラスターの完成です!!!!!!!
各ノードの詳細は、"kubectl describe node"で確認できます。

kubeuser@kubemaster1:~$ kubectl get nodes
NAME          STATUS   ROLES    AGE     VERSION
kubemaster1   Ready    master   68m     v1.18.0
kubemaster2   Ready    master   30m     v1.18.0
kubemaster3   Ready    master   3m16s   v1.18.0
kubeworker    Ready    <none>   37m     v1.18.0
kubeworker2   Ready    <none>   7m26s   v1.18.0
kubeuser@kubemaster1:~$ kubectl describe node kubemaster1
Name:               kubemaster1
Roles:              master
Labels:             beta.kubernetes.io/arch=amd64
                   beta.kubernetes.io/os=linux
                   kubernetes.io/arch=amd64
                   kubernetes.io/hostname=kubemaster1
                   kubernetes.io/os=linux
                   node-role.kubernetes.io/master=
Annotations:        kubeadm.alpha.kubernetes.io/cri-socket: /var/run/dockershim.sock
                   node.alpha.kubernetes.io/ttl: 0
                   projectcalico.org/IPv4Address: 192.168.1.251/24
                   projectcalico.org/IPv4IPIPTunnelAddr: 10.0.237.64
                   volumes.kubernetes.io/controller-managed-attach-detach: true
CreationTimestamp:  Wed, 01 Dec 2021 11:22:48 +0000
Taints:             node-role.kubernetes.io/master:NoSchedule
Unschedulable:      false
Lease:
 HolderIdentity:  kubemaster1
 AcquireTime:     <unset>
 RenewTime:       Wed, 01 Dec 2021 12:31:15 +0000
Conditions:
 Type                 Status  LastHeartbeatTime                 LastTransitionTime                Reason                       Message
 ----                 ------  -----------------                 ------------------                ------                       -------
 NetworkUnavailable   False   Wed, 01 Dec 2021 11:34:36 +0000   Wed, 01 Dec 2021 11:34:36 +0000   CalicoIsUp                   Calico is running on this node
 MemoryPressure       False   Wed, 01 Dec 2021 12:30:26 +0000   Wed, 01 Dec 2021 11:22:48 +0000   KubeletHasSufficientMemory   kubelet has sufficient memory available
 DiskPressure         False   Wed, 01 Dec 2021 12:30:26 +0000   Wed, 01 Dec 2021 11:22:48 +0000   KubeletHasNoDiskPressure     kubelet has no disk pressure
 PIDPressure          False   Wed, 01 Dec 2021 12:30:26 +0000   Wed, 01 Dec 2021 11:22:48 +0000   KubeletHasSufficientPID      kubelet has sufficient PID available
 Ready                True    Wed, 01 Dec 2021 12:30:26 +0000   Wed, 01 Dec 2021 11:34:07 +0000   KubeletReady                 kubelet is posting ready status. AppArmor enabled
Addresses:
 InternalIP:  192.168.1.251
 Hostname:    kubemaster1
Capacity:
 cpu:                2
 ephemeral-storage:  20511312Ki
 hugepages-2Mi:      0
 memory:             2035144Ki
 pods:               110
Allocatable:
 cpu:                2
 ephemeral-storage:  18903225108
 hugepages-2Mi:      0
 memory:             1932744Ki
 pods:               110
System Info:
 Machine ID:                 e0a37321b6f94a7aa6e6107d7f656965
 System UUID:                e0a37321-b6f9-4a7a-a6e6-107d7f656965
 Boot ID:                    3acfbc50-dc18-4c7b-a26e-e85d769d1349
 Kernel Version:             5.4.0-81-generic
 OS Image:                   Ubuntu 20.04.3 LTS
 Operating System:           linux
 Architecture:               amd64
 Container Runtime Version:  docker://20.10.7
 Kubelet Version:            v1.18.0
 Kube-Proxy Version:         v1.18.0
PodCIDR:                      10.0.0.0/24
PodCIDRs:                     10.0.0.0/24
Non-terminated Pods:          (9 in total)
 Namespace                   Name                                        CPU Requests  CPU Limits  Memory Requests  Memory Limits  AGE
 ---------                   ----                                        ------------  ----------  ---------------  -------------  ---
 kube-system                 calico-kube-controllers-77ff9c69dd-m5jbz    0 (0%)        0 (0%)      0 (0%)           0 (0%)         58m
 kube-system                 calico-node-7t474                           250m (12%)    0 (0%)      0 (0%)           0 (0%)         58m
 kube-system                 coredns-66bff467f8-cpd25                    100m (5%)     0 (0%)      70Mi (3%)        170Mi (9%)     68m
 kube-system                 coredns-66bff467f8-wtww9                    100m (5%)     0 (0%)      70Mi (3%)        170Mi (9%)     68m
 kube-system                 etcd-kubemaster1                            0 (0%)        0 (0%)      0 (0%)           0 (0%)         68m
 kube-system                 kube-apiserver-kubemaster1                  250m (12%)    0 (0%)      0 (0%)           0 (0%)         68m
 kube-system                 kube-controller-manager-kubemaster1         200m (10%)    0 (0%)      0 (0%)           0 (0%)         68m
 kube-system                 kube-proxy-6gq55                            0 (0%)        0 (0%)      0 (0%)           0 (0%)         68m
 kube-system                 kube-scheduler-kubemaster1                  100m (5%)     0 (0%)      0 (0%)           0 (0%)         68m
Allocated resources:
 (Total limits may be over 100 percent, i.e., overcommitted.)
 Resource           Requests    Limits
 --------           --------    ------
 cpu                1 (50%)     0 (0%)
 memory             140Mi (7%)  340Mi (18%)
 ephemeral-storage  0 (0%)      0 (0%)
 hugepages-2Mi      0 (0%)      0 (0%)
Events:
 Type    Reason                   Age                From                     Message
 ----    ------                   ----               ----                     -------
 Normal  NodeHasSufficientMemory  68m (x8 over 68m)  kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasSufficientMemory
 Normal  NodeHasNoDiskPressure    68m (x8 over 68m)  kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasNoDiskPressure
 Normal  NodeHasSufficientPID     68m (x7 over 68m)  kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasSufficientPID
 Normal  Starting                 68m                kubelet, kubemaster1     Starting kubelet.
 Normal  NodeHasSufficientMemory  68m                kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasSufficientMemory
 Normal  NodeHasNoDiskPressure    68m                kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasNoDiskPressure
 Normal  NodeHasSufficientPID     68m                kubelet, kubemaster1     Node kubemaster1 status is now: NodeHasSufficientPID
 Normal  NodeAllocatableEnforced  68m                kubelet, kubemaster1     Updated Node Allocatable limit across pods
 Normal  Starting                 68m                kube-proxy, kubemaster1  Starting kube-proxy.
 Normal  NodeReady                57m                kubelet, kubemaster1     Node kubemaster1 status is now: NodeReady

おわりに

今回、初めてkubernetesクラスターを構築してみましたが、
難しいと感じながらも、出来たときの達成感がめちゃくちゃあります!

また、とりあえずやってみようというような感じで構築するのではなく、
「クラスターの完成形をイメージした上で構築をする」、
これ大事かもしれません。

この記事が気に入ったら、サポートをしてみませんか?
気軽にクリエイターの支援と、記事のオススメができます!
ありがとうございます!!!!!!!
kujiraitakahiro
Kubernetes・コンテナ技術・Linuxなどオープンソース技術を中心とした記事を書いています。
